Short Pitch Roller Chains Conveyor Chain

Short Pitch Roller Chains Conveyor Chain is a precision roller chain used for continuous material conveying and mechanical power transmission where accurate pitch engagement, smooth sprocket operation, and reliable load transfer are required. Standard and customized sizes, lengths, materials, attachments, and configurations are available for OEM applications.





Parameter	Specification
Chain Type	Short Pitch Roller Chain
Construction	Inner plates, outer plates, pins, bushings and rollers
Standard Series	B Series / A Series
Standard	ISO 606 / DIN 8187; ANSI-compatible sizes available
Chain Arrangement	Simplex, duplex, triplex and other configurations
Available Chain Sizes	Common sizes from 06B to 48B; A-series sizes available according to application
Material	Carbon Steel 30Mn
Surface Treatment	Heat treatment
Color	Natural steel





Short-pitch geometry Provides consistent sprocket engagement and controlled chain articulation for continuous conveying and drive applications.
30Mn carbon-steel components Provide a practical balance of strength, machinability and wear resistance for general industrial chain service.
Heat-treated pins, bushings, rollers and plates improve resistance to wear and deformation under repeated loading.
Controlled component dimensions help maintain pitch accuracy and compatibility with standard matching sprockets.





Cumulative Pitch Tolerance: Maintained within +/- 0.02 mm per meter, eliminating uneven chain tension during high-speed continuous indexing.
Sprocket Compatibility: Machined to match DIN 8187 / ANSI B29.1 standard tooth profiles, reducing contact stress between rollers and sprocket teeth.
Smooth Articulation: Controlled bushing-to-pin clearance ensures continuous flexibility without dynamic stiff joints, preventing drive motor power loss.





Customization Item	Available Options
Chain Dimensions	Standard ISO/DIN or ANSI-compatible dimensions; engineered dimensions subject to drawing review
Chain Size / Pitch	06B–48B common B-series sizes; A-series sizes available according to requirement
Chain Length	Standard roll, specified number of links, or cut length
Strand Configuration	Simplex, duplex, triplex
Material	30Mn carbon steel; alternative material available subject to technical confirmation
Surface Treatment	Heat treatment; other surface finishes subject to corrosion and application requirements
Plate Configuration	Standard straight plates, extended plates or special plate geometry
Pin Configuration	Standard pins, extended pins, hollow pins or specified pin lengths where technically applicable
Roller Configuration	Standard roller, large/special roller configurations according to conveyor design
Attachments	Extended pins, attachment plates, tabs, brackets and other engineered attachments
Attachment Spacing	Specified pitch intervals or customized spacing according to conveyor layout
Connecting Components	Connecting links, offset links and other matching components
Marking	Logo, chain number, batch number or other identification marking





Raw Material Inspection – Incoming 30Mn carbon steel is checked against purchasing specifications before production.
Material Preparation – Steel is processed into chain plates, pins, bushings and rollers according to the specified chain dimensions.
Component Forming – Precision forming, punching, drilling and machining are used to establish the required component geometry.
Heat Treatment – Selected chain components undergo controlled heat treatment to improve hardness, wear resistance and mechanical performance.
Dimensional Inspection – Pitch, roller diameter, inner width, pin diameter, plate thickness and related dimensions are checked against the applicable chain specification.
Component Assembly – Pins, bushings, rollers and plates are assembled into the specified simplex, duplex, triplex or customized configuration.
Chain Length Inspection – Finished chains are checked for specified link count and dimensional consistency.
Mechanical Testing – Tensile-strength or related mechanical tests can be arranged according to the applicable specification and customer requirements.
Appearance Inspection – Finished chains are checked for abnormal deformation, damaged components, surface defects and assembly irregularities.
Final Packaging Inspection – Product quantity, identification, chain configuration and export packaging are verified before shipment.





Production Area: 50,000 m² dedicated manufacturing facility with integrated heat treatment and assembly lines.
Monthly Output: 120,000 meters of precision short pitch conveyor chains across standard and customized series.
Tooling & Machining Equipment: Automatic high-speed stamping presses, multi-station mesh belt heat-treatment furnaces, and automatic pin assembly machinery.
Compliance & Audit Support: ISO 9001 and ISO 14001 certified; third-party factory audits (SGS, TÜV Rheinland, Bureau Veritas) are welcomed upon agreement.
